- Wire rope / cable size: 9/16″ – 5/8″
- Minimum clips required (per termination): 3
- Minimum amount of turnback required: 12-3/4″ for 9/16″ or 13-1/2″ for 5/8″
- Drop Forged steel saddle
- Hot Dip Galvanized
- 80% efficiency rating
- Bolts are an integral part of the saddle. Nuts can be installed in such a way as to enable the operator to swing the wrench in a full arc for fast installation
- Assembled with standard heavy hex nuts
- Individually bagged or tagged with proper application instructions and warning information
- Meets or exceeds all requirements of ASME B3026 including identification, ductility, design factor, proof load and temperature requirements. Importantly, these wire rope clips meet other critical performance requirements including fatigue life, impact pro
- Fist Grip® wire clips meet or exceed the performance requirements of Federal Specification FF-C-450 Type III, Class 1, except for those provisions required of the contractor
