Green Pin UMJT Tycan® Grade 100 Connecting Link 1-3/16″ (WLL 14,960 lbs)

The Green Pin Tycan® Connecting Link GR10 is specifically designed for connecting Green Pin Tycan® chain slings. Made from grade 10 high-tensile steel, this link ensures durability and reliable performance for demanding applications.

• Fits Tycan® Chain: 13mm x 30mm (1/2″ x 1-3/16″)
• Working Load Limit (WLL): 6.80 tons (14,960 lbs)
• (a): 16mm (5/8″)
• (b): 83mm (3-9/32″)
• (c): 21mm (13/16″)
• (d): 32mm (1-1/4″)
• (e): 87mm (3-7/16″)
• (f): 24mm (15/16″)
• (g): 28mm (1-1/8″)
• (h): 20mm (25/32″)
• Material: Alloy Steel
• Finish: Painted
• Design Factor 4:1 (Lashing MBL 2:1)
