Jet PT Series Heavy Duty Manual Hoist Trolley 10 Ton Capacity

Jet PT Series heavy duty manual trolleys are built with heavy gauge steel for increased durability. Large steel wheels and thicker bearings provide smooth movement on a variety of beams. The built in bumper guards increase user safety and extend the life of the trolley.

• Working Load Limit: 20,000 lbs
• Minimum Beam Flange Width: 4.75″
• Maximum Beam Flange Width: 8.00″
• Maximum Beam Height: 5″
• Minimum Radius Curve: 67″
• Welded all-steel frame and powder coat finish provide maximum durability and protection
• Built-in bumper guards on the side plates increase safety and extend trolley life
• Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
• Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
• Complies with OSHA Regulations, ANSI / ASME B30.11 and B30.17 standards
• Certification- Load tested to 125% of capacity with certificate
