Jet PT Series Heavy Duty Manual Hoist Trolley 5 Ton Capacity

Jet PT Series heavy duty manual trolleys are built with heavy gauge steel for increased durability. Large steel wheels and thicker bearings provide smooth movement on a variety of beams. The built in bumper guards increase user safety and extend the life of the trolley.

• Working Load Limit: 10,000 lbs
• Minimum Beam Flange Width: 4.62″
• Maximum Beam Flange Width: 8.00″
• Maximum Beam Height: 5″
• Minimum Radius Curve: 55″
• Welded all-steel frame and powder coat finish provide maximum durability and protection
• Built-in bumper guards on the side plates increase safety and extend trolley life
• Hardened steel wheels and double sealed lubricated ball bearings provide smooth movement
• Easily adjustable to wide-flange H-beams, standard I-beams or curved track with the included spacer washers
• Complies with OSHA Regulations, ANSI / ASME B30.11 and B30.17 standards
• Certification- Load tested to 125% of capacity with certificate
