Maillon Rapide Large Opening Oval Quick Links provide a fast, easy, and durable connection. Large opening offers an easier connection to wider components.
- Material: Zinc Plated Steel
- Rod: custom-made steel used in surface processing, providing complete strength towards traction
- Nut: high safety steel (lead-free, systematic control carried out after drawing through Eddy currents and ultrasounds)
- Surface processing made through electrolytic coating on the entire material (rod & nut)
- Shape: Large Opening Oval
- Material Diameter: 1/2″
- 2755 lbs Working Load Limit
- ***WARNING – NOT RATED FOR CLIMBING OR LIFTING***
Recommendations:
- Keep to the working load limit WLL engraved in kg.
- Visual check of complete nut screwing compulsory; no thread must be showing
- Maillon Rapide quick links are only to be loaded along the major axis
- Maillon Rapide quick links should be carefully checked at regular intervals. If you are in any doubt about the safety of a quick link after checking, replace it with a new one
- When fastened with a wrench up to the proper tightening torque, Maillon Rapide quick links are considered a permanent connector
- Should always be fitted with parts made of same material
- When connected with chain, Maillon Rapide quick links should be of the same diameter.
- Never connect any Maillon Rapide quick links onto a lifting chain
- Made in France
