- Angular contact ball bearing wire rope swivel
- Working load limit 15 tons at 5:1 design factor
- Lubrication fitting
- Alloy steel, zinc-plated for corrosion resistance
- Length: 17.5″
- Width: 4.8″
- Height: 4″
- Wire Rope Size: 1″
- Clevis Pin Diameter: 1.50″
- Eye Hole Diameter: 2.03″
- Clevis Inside Width: 1.75″
- Eye Tang Thickness: 1.94″
- Eye to Clevis Pin Center Distance: 13.63″
- Working Load Limit: 15 tons (30,000 lbs)
