Stainless Steel Screw Pin D Shackle with Captive Pin made from grade 316 stainless steel for maximum corrosion resistance and durability making it ideal for marine applications and other corrosive environments. Features a captive pin that is not removable and will not fall out when shackle is opened, making it ideal for industrial or marine applications. The pin is also self-locking so it will not back out.
Specifications:
- Size (Shackle Body Thickness): 1/4″
- Throat Opening (Width Between Ears): 0.48″
- Throat Depth: 0.85″
- Pin Size: 0.23″
- Pin Type: Captive Screw Pin
- Finish: Plain
- Material: Type 316 Stainless Steel
- Working Load Limit: 0.38 tons (750 lbs)
