Features:
- For vertical lifting, transporting and turning of all steel plates and structures from all positions
- With articulated lifting shackle for universal lifting flexibility at various angles
- Equipped with an articulated lifting shackle for flexible lifting angles up to 90 degrees (for lifting at angles over 45 degrees, check WLL reduction)
- Longer plates can be lifted without the use of a spreader beam when using two clamps on a two legged chain sling
- Equipped with a safety mechanism that prevents slippage during lifting and lowering operations
- Clamp can lock in both open and closed positions
- Minimum Working Load Limit is 10% of maximum Working Load Limit
- ✻ Note: Surface hardness of the material lifted must not exceed 37 HRC / 345 Hb ✻
Specifications:
- Working Load Limit: 33,000 lbs (15.00 tons)
- Jaw Opening: 0″ – 3.00″
- Eye Diameter: 3.35″
- Eye Thickness: 1.89″
- Made in Holland
