Features:
- For vertical lifting, handling and transporting of Holland Profile (HP) ship building structures from all positions
- With articulated lifting shackle for universal lifting flexibility at various angles
- Equipped with an articulated lifting shackle for flexible lifting angles up to 90 degrees (for lifting at angles over 45 degrees, check WLL reduction)
- Standard with 2 pivots for extra powerful clamping force
- Equipped with a safety mechanism that prevents slippage during lifting and lowering operations
- Clamp can lock in both open and closed positions
- Minimum Working Load Limit is 10% of maximum Working Load Limit
- ✻ Note: Surface hardness of the material lifted must not exceed 37 HRC / 345 Hb ✻
Specifications:
- Working Load Limit: 11,000 lbs (5.00 tons)
- Jaw Opening: 0″ – 1.77″
- Eye Diameter: 2.76″
- Eye Thickness: 0.79″
- Made in Holland
