- Quenched and Tempered Alloy Steel
- At least 25% greater WLL than traditional G80 products
- Manufactured in accordance with DIN PAS 1061, EN 1677-1 and ASTM A952/A 952M
- Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
- Design Factor 4:1
- Fatigue rated to 20,000 cycles at 1.5 times the WLL
- Tempering temperature minimum 400°C
- Fits Chain Size: 3/4″
- Working Load Limit (WLL): 35,300 lbs (16.00 tons)
