Yoke 5/8″ Grade 100 Clevis Cradle Grab Hook (X-042) (WLL 22,600 lbs)

Yoke X-042 G-100 Clevis Cradle Grab Hooks feature supporting wings which prevent chain link deformation and enables full working load limit of the chain.

• Quenched and Tempered Alloy Steel
• At least 25% greater WLL than traditional G80 products
• Testing according to DIN PAS 1061 and ASTM A952/A 952M
• Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
• Design Factor 4:1
• Fatigue rated to 20,000 cycles at 1.5 times the WLL
• Tempering temperature minimum 400°C
• Fits Chain Size: 5/8″
• Working Load Limit (WLL): 22,600 lbs (10.00 tons)
