Yoke 8-057 Grade 80 Weld-On Lifting Point 8 Ton (WLL 17,000 lbs)

Features:

• Pivots through 180°
• Proof tested to 2.5 times the WLL
• Fatigue rated to 1.5 times the WLL
• Manufactured from forged alloy steel, quenched and tempered
• Manufactured and tested in accordance with EN1677-1
• Load rated parts are 100% magnaflux crack detected
• Individual forged parts are traceable to Test Certification
• All YOKE Lifting points meet or exceed all the requirements of ASME B30.26
• Lugs designed to assist the welding process

Specifications:

• Working Load Limit: 17,000 lbs (8.00 tons)
• (A): 121mm (4.76″)
• (B): 73mm (2.87″)
• (C): 68mm (2.68″)
• (D): 26mm (1.02″)
• (E): 26mm (1.02″)
• (F): 122mm (4.8″)
• (G): 53mm (2.09″)
• (H): 69mm (2.72″)
• (L): 169mm (6.65″)
• (W): 60mm (2.36″)
• (HV): 10mm (0.39″)
• (a): 4mm (0.16″)
