Yoke 8-838 Bolt Type Anchor Shackle 5/16″ Forged – Plain

Features:

• Forged carbon steel with alloy pin
• 100% magnaflux crack detection during manufacturing
• 20,000 cycle fatigue rated to 1.5 times Working Load Limit
• Minimum Ultimate Load is 6 times the Working Load Limit
• Maximum Proof Load is 2 times the Working Load Limit

Specifications:

• Size (Shackle Body Thickness): 8mm (5/16″)
• Throat Opening (Width Between Ears): 12mm (0.47″)
• Throat Depth: 31mm (1.22″)
• Pin Size: 9.5mm (0.37″)
• Pin Type: Bolt, Nut, & Cotter
• Finish: Plain
• Material: Carbon Steel
• Working Load Limit: 0.75 tons (1650 lbs)
• Design Factor 6:1
