Yoke 8-M015 Grade 80 Connecting Link 1″ (WLL 46,738 lbs)

Yoke 8-M015 G-80 Connecting Link is designed for attaching chain to fittings and hardware.

Features:

• Quenched and Tempered Alloy Steel
• Tested according to DIN EN 1677
• Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
• Dacromet surface finish for enhanced corrossion resistance

Specifications:

• Fits Chain: 26mm (1″)
• Working Load Limit (WLL): 21.20 tons (46,738 lbs)
• (A): 55mm (2-3/16″)
• (B): 62mm (2-7/16″)
• (D): 30mm (1-3/16″)
• (K): 162mm (6-3/8″)
• Material: Alloy Steel
• Finish: Dacromet
• Design Factor 4:1
