Yoke 8-M015 Grade 80 Connecting Link 7/8″ (WLL 33,069 lbs)

Yoke 8-M015 G-80 Connecting Link is designed for attaching chain to fittings and hardware.

Features:

• Quenched and Tempered Alloy Steel
• Tested according to DIN EN 1677
• Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
• Dacromet surface finish for enhanced corrossion resistance

Specifications:

• Fits Chain: 22mm (7/8″)
• Working Load Limit (WLL): 15.00 tons (33,069 lbs)
• (A): 49mm (1-7/8″)
• (B): 59mm (2-5/16″)
• (D): 24mm (7/8″)
• (K): 152mm (6″)
• Material: Alloy Steel
• Finish: Dacromet
• Design Factor 4:1
