Yoke 8-S291 Digital Stainless Steel Eye Point (M12-1.75 x 18mm)

Features:

• Rotates through 360° adjustable in the direction of the load
• Manufactured from stainless steel. Captive bolt with high WLL
• Manufactured and tested in accordance with DGUV GS-OA 15-04
• Bolts are Metric thread (ASME / ANSI B18.3.1M)
• Proof tested to 2.5 times the WLL & Fatigue rated to 1.5 times the WLL
• Meet or exceed all the requirements of ASME B30.26
• Used in different applications such as chemical oil coal industries, food processing, clean room and precision instrument

Specifications:

• Bolt Diameter/Thread: M12-1.75
• Thread Projection Length: 18mm
• Working Load Limit (WLL): 0.50 tons (1100 lbs)
• Design Factor 4:1
