Yoke X-173 Grade 100 Alloy Eye Latch Hook 7/8″ (WLL 41,887 lbs)

Features:

• Quenched and Tempered Alloy Steel
• At least 25% greater WLL than traditional G80 products
• Manufactured in accordance with EN 1677- 2 and ASME B30.26
• Proof Load tested at 2.5 times the WLL with certification for each batch manufactured
• Fatigue rated to 20,000 cycles at 1.5 times the WLL
• Tempering temperature minimum 400°C
• Magnaflux crack detection is performed 100% on each batch

Specifications:

• Fits Chain Size: 22mm (7/8″)
• Working Load Limit (WLL): 19.00 tons (41,887 lbs)
• (A): 73mm (2.87″)
• (D): 62mm (2.44″)
• (d): 32mm (1.26″)
• (H): 64mm (2.52″)
• (K): 260mm (10.24″)
• (P): 68mm (2.68″)
• (P1): 62mm (2.44″)
• (T): 52mm (2.05″)
• Material: Alloy Steel
• Finish: Painted
• Design Factor 4:1
