- 25% greater WLL than traditional Grade 80 products
- Proof Load tested at 2.5 times the WLL with batch certification
- Fatigue rated to 20,000 cycles at 1.5 times the WLL
- Minimum tempering temperature of 400°C
- Manufactured in accordance with EN 1677- 2 and ASME B30.26
- Magnaflux crack detection is performed 100% on each batch
- Design Factor 4:1
- Material: Alloy Steel
- Finish: Painted
- Grade: 100
- Dimensions:
- A: 46mm (1.8″)
- B: 48mm (1.9″)
- C: 38mm (1.5″)
- D: 21mm (0.8″)
- G: 122mm (4.8″)
- H: 38mm (1.5″)
- K: 218mm (8.6″)
- L: 277mm (10.9″)
- P: 35mm (1.4″)
- P1: 31mm (1.2″)
- T: 31mm (1.2″)
- Fits Chain Size: 13mm (1/2″)
- Working Load Limit: 6.7 tons (13,400 lbs)
