- Proof Load tested at 2.5 times the WLL with batch certification
- Fatigue rated to 20,000 cycles at 1.5 times the WLL
- Minimum tempering temperature of 400°C
- Manufactured in accordance with EN 1677-3
- Manufactured in accordance with ASTM A952/A952M, DIN PAS 1061.
- Magnaflux crack detection is performed 100% on each batch
- Design Factor 4:1
- Material: Alloy Steel
- Finish: Painted
- Grade: 100
- Dimensions:
- A: 41mm (1.6″)
- B: 35mm (1.4″)
- D: 16mm (0.6″)
- H: 31mm (1.2″)
- K: 226mm (8.9″)
- O: 49mm (1.9″)
- P: 71mm (2.8″)
- Fits Chain Size: 10mm (3/8″)
- Working Load Limit: 4 tons (8000 lbs)
